About Induction Gold Melting Furnace 2 KG
Gold Melting Induction Furnace we offer is designed for making the gold jewellery melting and producing easier and faster. It is powered by electric energy, and works automatically and efficiently due to its hi-tech components and melting mechanisms. The furnace is easy to install & operate due to its easy functions and ideal dimension & weight.
Technical Details:
- Input Voltage - 415 VAC
- Power Supply - Three Phase
- Melting Material - Gold
- Brand - New Tech
- Technology - IGBT
- Max Temperature - 1200 degree
- Melting Time - 5 min
- Frequency - 50 HZ / 60 HZ
- Absorbed Power - 5 Kw
- Capacity of Crucible - 2 kg
- Temperature Measurement - K type
- Cooling Water Temperature - 20 to 30o
- Water Pressure - 3 Maximum
- Water Flow - 20 Lit/ Min
- Weight ( with chilling unit ) - 220 Kg
Advanced Digital Control for Precision MeltingThe digital meter display allows you to monitor temperature and operating status in real-time, ensuring consistent accuracy (1C) every batch. This feature makes the furnace user-friendly and reduces the chance for manual errors, supporting high-quality results whether used in jewellery shops or small-scale workshops.
Efficient & Safe OperationBuilt-in safety mechanisms such as overheat and overcurrent protection safeguard both users and the furnace itself. The efficient water cooling system, with a built-in recirculation unit, maintains optimal operating temperatures, allowing for safe operation even during extended use.
Versatile and Portable DesignWith dimensions of approximately 450 x 400 x 600 mm and weighing around 45-55 kg, the furnace is portable yet robust. Its capacity and fast melting time make it suitable for various precious metals processing requirements, enhancing productivity in small-scale casting units and goldsmith workshops.
FAQ's of Induction Gold Melting Furnace 2 KG:
Q: How does the Induction Gold Melting Furnace 2 KG ensure safe operation during use?
A: This furnace is equipped with overheat and overcurrent protection systems that automatically shut off or regulate power in unsafe conditions. The built-in water recirculation cooling system further ensures stable temperatures, minimizing the risk of overheating.
Q: What metals can be melted in this furnace, and what is its maximum capacity?
A: The furnace can efficiently melt gold, silver, copper, and other precious metals, with a maximum batch capacity of 2 kg.
Q: When should I use this furnace for melting applications?
A: This furnace is best suited for jewellery manufacturing, small-scale casting, and goldsmith workshops where fast, accurate melting of precious metals (up to 1200C) is required within minutes.
Q: Where can I operate this furnace safely?
A: The furnace is designed for industrial indoor environments such as jewellery shops, goldsmith studios, and small foundries. Ensure there is adequate ventilation and access to a single-phase 220V-240V power supply.
Q: What is the melting process and how long does it take per batch?
A: Once loaded with metals in the graphite crucible, simply select your settings on the digital meter. The furnace melts the contents in approximately 3-8 minutes per batch, depending on the material and quantity.
Q: What are the primary benefits of using this induction melting furnace?
A: Key advantages include rapid melting times, high energy efficiency, precise temperature control, enhanced safety features, and portability. These features reduce downtime and metal loss, improving productivity and cost-efficiency for small-scale operations.
Q: Is the furnace fully automatic, and does it require computerization?
A: The furnace is fully automatic and does not require any computerized controls, making it easy to operate for users without advanced technical knowledge.
